Lere
LED Elevated Runway Edge and Threshold/End Light
Ideal for the runway edge and threshold/end lighting on ICAO CAT I, II and III, FAA and military runways, LERE mean lower loads, lower size of CCRs and transformers and thus low life cycle costs.
DIMENSION
Diameter
Ø175 mm
Height
ICAO 320 mm, FAA 14″=355 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
IEC
FAA
NATO
CAA
TCCA
ENAC
EASA
CASA
POWER CONSUMPTION
Fixture without arctic kit
29,2 VA
Fixture with arctic kit
49,1 VA
29,2 VA
Fixture with arctic kit
49,1 VA
ADDITIONAL OPTIONS
Monitoring:
Electronic device that returns information of open circuit at the secondary of the isolation transformer in case of failure of a luminous LED source or control board.
