Twof

​Inset Taxiway Edge Light

An omnidirectional light suitable for 8″ and 12″ diameter bases, the TWOF is a taxiway edge light for ICAO, FAA and military taxiways as well as for FAA taxiway intersections. The lamp offers stable chromaticity thanks to the use of dichroic filters. It has a rated life of 1500 hours at full intensity, but over 3000 hours in field operating conditions. Its drop-forged dome and cast aluminum lower cover make the fitting sturdy, but lightweight too for easy handling in the field.

    DIMENSION

    Diameter
    8″

    Overhang
    6.35 mm

    Basic depth
    125 mm

    Diameter
    12″

    Overhang
    6.35 mm

    Basic depth
    150 mm

    COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS

    ICAO
    IEC
    FAA
    NATO
    CAA
    TCCA
    CASA

    POWER CONSUMPTION

    Taxiway Edge Blue
    1×48 W
