Twof
Inset Taxiway Edge Light
An omnidirectional light suitable for 8″ and 12″ diameter bases, the TWOF is a taxiway edge light for ICAO, FAA and military taxiways as well as for FAA taxiway intersections. The lamp offers stable chromaticity thanks to the use of dichroic filters. It has a rated life of 1500 hours at full intensity, but over 3000 hours in field operating conditions. Its drop-forged dome and cast aluminum lower cover make the fitting sturdy, but lightweight too for easy handling in the field.
DIMENSION
Diameter
8″
Overhang
6.35 mm
Basic depth
125 mm
Diameter
12″
Overhang
6.35 mm
Basic depth
150 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
IEC
FAA
NATO
CAA
TCCA
CASA
POWER CONSUMPTION
1×48 W
