Litc

LED Inset Taxiway Centreline, Stop Bar and Intermediate Holding Position Light

A bidirectional or unidirectional, 8″ or 12” diameter light, the LITC is used at the taxiway centreline, stop bar and intermediate holding positions for ICAO CAT I, II and III, FAA and military taxiways. With a LED rated life of over 100,000 hours in field operating conditions, its light output is variable like a traditional halogen lamp, as indicated by the FAA directive. The in-built electronic is strong and highly resistant to shocks and vibrations and can immediately detect and create an alert in the event of an internal fault. A 6.35 mm protrusion strongly reduces vibrations to aircraft, increasing its lifetime. Its drop-forged dome and cast aluminum lower cover make the fitting sturdy, but lightweight too for easy handling in the field.

    DIMENSION

    Diameter
    8″ or 12″

    Overhang
    6.35 mm

    Device depth
    85 mm

    Basic depth
    125 mm (8″ fixture) or 150 mm (12″ fixture)

    COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS

    ICAO
    EASA
    FAA
    IEC
    NATO
    CAA
    TCCA
    CASA
    ENAC

    POWER CONSUMPTION

    Unidirectional 8”-12” (w/o Arctic Kit)
    7 VA (1 plug)

    Unidirectional 8” (with Arctic Kit)
    27 VA (1 plug)

    Unidirectional 12” (with Arctic Kit)
    47 VA (1 plug)

    Bidirectional 8″-12” (w/o Arctic Kit)
    12 VA (1 plug) / 14 VA (2 plugs)

    Bidirectional 8″ (with Arctic Kit)
    32 VA (1 plug) / 54 VA (2 plugs)

    Bidirectional 12″ (with Arctic Kit)
    52 VA (1 plug) / 94 VA (2 plugs)

    ADDITIONAL OPTIONS

    Fuse Cut-out:

    Electric device, placed in parallel with each lamp, that ensures the continuity of the secondary circuit in case of lamp failure.
