Twcd
Inset Taxiway Centreline and Stop Bar Light
A bidirectional or unidirectional 8″ diameter light, the TWCS is used in taxiway centreline, stop bar and intermediate holding positions for ICAO CAT I, II and III, FAA and military taxiways. The light comes with an adaptor ring that also makes it suitable for 12″ diameter bases. Consisting of two lamps, the light offers stable chromaticity thanks to the use of dichroic filters. It has a rated life of 1500 hours at full intensity, but over 3000 hours in field operating conditions. Its drop-forged dome and cast aluminum lower cover make the fitting sturdy, but lightweight too for easy handling in the field.
DIMENSION
Diameter
8″
Overhang
6.35 mm
Basic depth
125 mm
Diameter
12″
Overhang
6.35 mm
Basic depth
150 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
IEC
FAA
NATO
ENAC
POWER CONSUMPTION
1×30 W
Lamp 045
1×48 W
Lamp 060
2×30 W
Lamp 090
2×48 W
ADDITIONAL OPTIONS
Fuse Cut-out:
Electric device, placed in parallel with each lamp, that ensures the continuity of the secondary circuit in case of lamp failure.
