Slte
Inset Threshold/End Light
A bidirectional or unidirectional 12″ diameter light, the SLTE is used as a threshold/runway end light for ICAO CAT I, II and III, and military runways. The light offers stable chromaticity thanks to the use of dichroic filters. The lamp has a rated life of 1000 hours at full intensity, but over 3000 hours in field operating conditions. The cast aluminum dome and lower cover make the fitting sturdy, but lightweight too for easy handling in the field.
DIMENSION
Diameter
12″
Overhang
12.7 mm
Basic depth
150 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
IEC
ICAO
IAAE
NATO
CAA
AENA
POWER CONSUMPTION
Threshold/End Green/Red
3×105 W
Runway End Red
1×105 W
Threshold Green
2×105 W
Bidirectional (with Arctic Kit)
49 VA (1 plug) / 72 VA (2 plugs)
ADDITIONAL OPTIONS
Fuse Cut-out:
Electric device, placed in parallel with each lamp, that ensures the continuity of the secondary circuit in case of lamp failure.
