Lirn
LED Inset Runway End Light
A unidirectional, 12″ diameter runway end light for ICAO CAT I, II and III, and military runways, the LIRN has a LED rated life of over 100,000 hours in field operating conditions. Its light output is variable like a traditional halogen lamp, as indicated by the FAA directive. It has a drop-forged dome and cast aluminum lower cover that make the fitting sturdy, but lightweight too for easy handling in the field.
DIMENSION
Diameter
12″
Overhang
6.35 mm
Device depth
106 mm
Basic depth
150 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
EASA
IEC
NATO
CAA
IAAE
ENAC
POWER CONSUMPTION
Unidirectional (w/o Arctic Kit)
18 VA
Unidirectional (with Arctic Kit)
58 VA
ADDITIONAL OPTIONS
Fuse Cut-out:
Electric device, placed in parallel with each lamp, that ensures the continuity of the secondary circuit in case of lamp failure.
Download
Catalogues
Manuals
Certificates
