Lire
Threshold and end, both directions.
DIMENSION
Diameter
8″
Overhang
6.35 mm
Device depth
106 mm
Basic depth
150 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
EASA
FAA
IEC
NATO
CAA
IAAE
CASA
ENAC
POWER CONSUMPTION
Unidirectional (w/o Arctic Kit)
31 VA
Unidirectional (with Arctic Kit)
71 VA
Bidirectional (w/o Arctic Kit)
65 VA (1 plug) / 62 VA (2 plugs)
Bidirectional (with Arctic Kit)
105 VA (1 plug) / 142 VA (2 plugs)
ADDITIONAL OPTIONS
Arctic Kit:
Electric device, thermostatically controlled, that heats the area near the prisms (inset fixtures) or the external glass lens (elevated fixtures) favoring the melting of the ice and/or snow; thus avoids the light beam obstruction with a behaviour similar to a traditional halogen lamp. Less than 12 VA.
Monitoring:
Electronic device that returns information of open circuit at the secondary of the isolation transformer in case of failure of a luminous LED source or control board.
