Lhi
Flush guidance for helipads.
In-pavement marking for heliports and vertiports, certified to ICAO.
DIMENSION
Diameter
8”
Overhang
6,35 mm
Basic depth
125 mm
Device depth
85 mm
Diameter
12”
Overhang
6,35 mm
Basic depth
150 mm
Device depth
85mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
IEC
NATO
ENAC
POWER CONSUMPTION
WHITE (series)
20 VA
GREEN – YELLOW (series)
12 VA
WHITE (parallel)
42 VA
GREEN – YELLOW (parallel)
21 VA
20 VA
GREEN – YELLOW (series)
12 VA
WHITE (parallel)
42 VA
GREEN – YELLOW (parallel)
21 VA
