Fau

Elevated Approach, Threshold and Runway End Light

FAU is used for the approach, threshold, and runway end for ICAO CAT I, II, and III, and military runways as well as for stop bar lighting on ICAO and FAA taxiways. A single lamp between 65W through 200W allows for easy and quick replacement without the need for tools. It has a heat resistant white, red or green front glass for easy cleaning. It has a rated life of 1000 hours at full intensity and 3000 hours in field operating conditions.

    DIMENSION

    Configuration P-001
    d Ø204 mm; h 320 mm; w 183 mm

    Configuration C-050
    d Ø204 mm; h 320 mm; w 183 mm

    Configuration C-250
    d Ø204 mm; h MIN 355 mm MAX 2265 mm; w 183 mm

    COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS

    ICAO
    FAA
    IEC
    CAA
    NATO
    IAAE

    POWER CONSUMPTION

    White
    150 W
    Approach Side Row red
    150 W
    FAA Stop Bar
    100 W
    Runway End
    65 W
    Threshold Green
    200 W
    Threshold WingGreen
    200 W
