Spck
Connect the primary circuit, fast.
Plug-and-receptacle connectors for 5kV shielded primary cable, with an outer shield for screen continuity.
DIMENSION
C: 6,4 – 8,4 mm
D: 8,1 – 10,9 mm
E: 10,7 – 14,9 mm
F: 14,6 – 19,9 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
FAA
POWER CONSUMPTION
–
ADDITIONAL OPTIONS
Applications:
The connection of the series isolation transformers to the power cables requires primary connector kits that can be applied to cable ends in a few minutes by the electrical installer following simple illustrated instructions.
SPCK primary kits are designed for 5 kV screened cables; they are equipped with integral shield connection with external wire to maintain the continuity of the shield across the cable connection or isolation transformer.
Metal plug and receptacle fittings are crimped onto the conductors and then inserted into the moulded rubber housings. Upon pushing the assemblies together, the circuit is ready for immediate use. Primary kits provide both a plug and a receptacle. One kit is required for each transformer location for the ends of the series cable sections. The circuits may be readily disconnected for testing or for replacing faulty equipment and then quickly rejoined for continued use.
