Ske
Connect the primary circuit, fast.
Plug-and-receptacle connectors for 5kV shielded primary cable, with an outer shield for screen continuity.
DIMENSION
A: 2,8 – 4,0 mm
B: 2,8 – 3,4 mm
C: 3,8 – 5,5 mm
D: 5,0 – 8,0 mm
E: 8,5 – 13,5 mm
F: 11,5 – 18,0 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
ICAO
FAA
POWER CONSUMPTION
–
ADDITIONAL OPTIONS
Main options:
When it is not possible the direct coupling between the lights and the relative isolation transformers, to realize suitable secondary extensions two-pole connector kits are available for on-site direct application to the cable ends in a few minutes by the electrical installer following simple illustrated instructions.
SKE secondary kits are designed for 600 V cables and 20 A maximum current.
Metal plug and receptacle fittings are crimped onto the conductors and then inserted into the molded rubber bodies.
Plug and receptacle secondary kits are available, suitable for single-pole or two-pole cables.
