Rclf
Inset Runway Centreline and Rapid Exit Taxiway Indicator Light (R.E.T.I.L.)
A bidirectional or unidirectional 8″ diameter light, the RCLF is suitable as a runway centreline light for ICAO CAT I, II and III, FAA and military runways and as a rapid exit taxiway indicator light for ICAO and FAA RWSL, THL and RIL (L-850T) applications. It can also be used for ICAO centreline lighting on rapid exit taxiways in special applications. The light comes with an adaptor ring for installation on 12″ diameter bases. The light offers stable chromaticity thanks to the use of dichroic filters. The lamp has a rated life of 1500 hours at full intensity, but over 3000 hours in field operating conditions.
DIMENSION
Diameter
8″
Overhang
6.35 mm
Basic depth
125 mm
Diameter
12″
Overhang
6.35 mm
Basic depth
150 mm
COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS
FAA
ICAO
IEC
NATO
CAA
IAAE
POWER CONSUMPTION
Lamp 045
1x48W 6.6A with reflector
Lamp 090
2x48W 6.6A with reflector
Lamp 100
1x105W 6.6A with reflector (L-850T)
ADDITIONAL OPTIONS
Fuse Cut-out:
Electric device, placed in parallel with each lamp, that ensures the continuity of the secondary circuit in case of lamp failure.
