Lita

LED Inset Apron Light

An omnidirectional, 8” diameter light, that is suitable for 8″ and 12″(with adaptor ring) diameter bases, the LITA is used as an aircraft stand maneuvering guidance light for ICAO aircraft stands. With an LED rated life of over 100,000 hours in field operating conditions, its light output is variable like a traditional halogen lamp, as indicated by the FAA directive. The in-built electronic is strong and highly resistant to shocks and vibrations while a protection ring prevents damages caused by mechanical impacts in maneuvering operations. Its drop-forged dome and cast aluminum lower cover make the fitting sturdy, but lightweight too for easy handling in the field.

    DIMENSION

    Diameter
    8″ or 12″

    Overhang
    11 mm

    Device depth
    90 mm

    Basic depth
    125 mm (8″ fixture) or 150mm (12″ fixture)

    COMPLIES WITH THE CURRENT EDITION OF THE FOLLOWING SPECIFICATIONS

    ICAO
    IEC
    FAA

    POWER CONSUMPTION

    Omnidirectional, Series Circuit
    20 VA

    Omnidirectional, Parallel Circuit
    21 VA
